Consumables
Model name
Barcode Label
Classification
Barcode label
Product Characteristics
Install the barcode printer to print the bar code printer, distributing the bar code printer, polyji, polyji, polyji, polyji, and special labels
Types of Print Format
Thermal paper
Characteristics
- Print as a column without ribbon
- Applying heat-sensitive material to the label
- Could be bleached/damaged by heat or direct sunlight
Applications
- Areas that do not require long retention
- Receipt, etc.
A transcription paper
Characteristics
- Transfer heat to the ribbon, adhere the carbon on the ribbon, and print
- Most all label formats
- Ribbon is essential
Applications
- Areas that do not require long retention
- Receipt, etc.
- All general fields
Type of label type
GAP label
Characteristics
- Check the label size at the interval between labels on the barcode printer
- Labels in Common Format
- It is cut to fit the size of the label, so it is easy to take off and use one by one
- Can be produced in any size you want
Marking label
Characteristics
- Check the label size with black markings on the back of the label on the barcode printer, or holes in the label at regular intervals
- Select if necessary according to the shape of the label
- Applies to GAP or Continue labels and can be used together
- Marking at the desired size interval
Continuse label
Characteristics
- A label that is disconnected or connected as one without marking
- Set label size according to the output command from the printer
- Generally used with bar code printers with additional Cutter function
- You can freely print out the label of the desired size without changing the label
Type according to label material
Art magazine
Characteristics
- Barcode Label of General Paper
- Tends to tear easily
- There is a risk of damage to friction, contaminants (water/oil), etc.
- The cheapest
Recommended Ribbon
- Ribbon of WAX or WAX RESIN type
Applications
- A place where labels are prone to damage due to high pollutants (electronic parts, etc.)
A place of circulation
Characteristics
- A label that is about the middle of art and PP paper
- It doesn't tear easily and there is little risk of damage to contaminants
Recommended Ribbon
- Ribbon of WAX or WAX RESIN type
Applications
- All general fields such as part identification tables, box labels, etc.
- Places where labels are susceptible to damage to contaminants
- Asset label, electronic component label, etc.
Special Label
Characteristics
- Labels for Special Use
- Special use such as high temperature (200 degrees or higher) or care label
- Customized according to purpose
Recommended Ribbon
- Ribbon of WAX or WAX RESIN type
Applications
- High temperature label
- Care label for hospital patient recognition
- Clothes Label, etc.
